Piper PA-31 Navajo
Explore the Piper PA-31 Navajo in side view and top view to compare its silhouette and proportions.
From Wikipedia
The Piper PA-31 Navajo is a family of twin-engined low-wing tricycle gear utility aircraft designed and built by Piper Aircraft for small cargo and feeder airlines, and as a corporate aircraft. Production ran from 1967 to 1984. It was license-built in a number of Latin American countries.
Summary of “Piper PA-31 Navajo” from Wikipedia, the free encyclopedia, used under CC BY-SA 4.0. Retrieved 2026-10-11.
Download
Free to use, with credit
Use these drawings for anything, commercial too, under Creative Commons Attribution 4.0 International. Credit us like this:
Drawing of the Piper PA-31 Navajo by AirwayControl Aircraft Library (https://aircraft.intelsystems.ai/aircraft/PA31/), CC BY 4.0Specifications
- Length
- 9.94 m32.6 ft
- Wingspan
- 12.4 m40.7 ft
- Max take-off weight
- 2.95 t6,500 lb
- Typical seats
- 8
- Cruise speed
- 383 km/h238 mph
- Max speed
- 420 km/h261 mph
- Range
- 1,875 km1,165 mi
- Ceiling
- 8,000 m26,200 ft
- Engines
- 2× Lycoming TIO-540-A (piston)
- Power
- 2× 310 hp
- First flight
- 1964
From the AirwayControl spec register, curated from Wikipedia and manufacturer pages. Figures vary by variant.
