Chengdu J-10C
Explore the Chengdu J-10C in side view and top view to compare its silhouette and proportions.
From Wikipedia
The Chengdu J-10, also known as Menglong is a Chinese medium-weight, single-engine, multirole combat aircraft using a delta wing and canard design, with a maximum speed of Mach 1.8. It is produced by the Chengdu Aircraft Corporation (CAC) for the People's Liberation Army Air Force (PLAAF) of China, and exported to the Pakistan Air Force (PAF) and the Uzbekistan Air and Air Defence Forces.
Summary of “Chengdu J-10” from Wikipedia, the free encyclopedia, used under CC BY-SA 4.0. Retrieved 2026-10-11.
Download
Free to use, with credit
Use these drawings for anything, commercial too, under Creative Commons Attribution 4.0 International. Credit us like this:
Drawing of the Chengdu J-10C by AirwayControl Aircraft Library (https://aircraft.intelsystems.ai/aircraft/J10/), CC BY 4.0Specifications
- Length
- 16.9 m55.4 ft
- Wingspan
- 9.8 m32.2 ft
- Range
- 1,850 km1,150 mi
- Engines
- 1 × WS-10 B afterburning turbofan engines
- Power
- 89.17 kN (20,050 lbf) thrust , 135 kN - 144 kN with afterburner
- First flight
- 1998
- In service
- 2004
From the AirwayControl spec register, curated from Wikipedia and manufacturer pages. Figures vary by variant.
