Japan Airlines Boeing 767-300ER

In Japan Airlines colours · Japan

Explore the Boeing 767-300ER in Japan Airlines livery in side view and top view to compare its silhouette and proportions.

Boeing 767-300ER in Japan Airlines livery, side profile

54.9 m

Boeing 767-300ER in Japan Airlines livery, top view

From Wikipedia

The Boeing 767 is an American wide-body airliner developed and manufactured by Boeing Commercial Airplanes. The airliner design was launched as the 7X7 program on July 14, 1978, the prototype first flew on September 26, 1981, and it was certified on July 30, 1982. The initial 767-200 variant entered service on September 8, 1982, with United Airlines, and the extended-range 767-200ER in 1984. It was stretched into the 767-300 in October 1986, followed by the extended-range 767-300ER in 1988, the most popular variant. The 767-300F, a production freighter version, debuted in October 1995. It was stretched again into the 767-400ER from September 2000.

Read on Wikipedia

Summary of “Boeing 767” from Wikipedia, the free encyclopedia, used under CC BY-SA 4.0. Retrieved 2026-10-11.

Download

Free to use, with credit

Use these drawings for anything, commercial too, under Creative Commons Attribution 4.0 International. Credit us like this:

Drawing of the Boeing 767-300ER in Japan Airlines colours by AirwayControl Aircraft Library (https://aircraft.intelsystems.ai/aircraft/B763/JAL/), CC BY 4.0

Airline names and colour schemes are trademarks of their owners; the licence covers our drawing, not their marks.

Specifications

Length: 54.9 m
Wingspan: 47.6 m
Max take-off weight: 186.9 t
Typical seats: 269
Cruise speed: 851 km/h
Max speed: 913 km/h
Range: 11,070 km
Ceiling: 13,100 m
Engines: 2× CF6-80C2 / PW4000
Power: 2× 273 kN
First flight: 1986
In service: 1986

From the AirwayControl spec register, curated from Wikipedia and manufacturer pages. Figures vary by variant.
